Roller coaters for varnishes

Roller coaters are suitable for coating of all plane surfaces, such as wood panels, metal, glass or rubber.

Roller coater mod. TFT/3s. Suitable to apply UV base coats. Spreading amount from 10 to 40 gr/m2



Roller coater mod. TFT/3. Suitable to apply UV base coats and top coats. Spreading amount: Base coats from 10 to 40 gr/m2 - Top coats from 5 to 10 gr/m2



Main features:

  • PLC for electronical control.
  • Separate motorization of rolls. Single speed regulation by means of inverters.
  • Rolls speeds automatic synchronization for cleaning.
  • Upper rolls up and down movement are motorized, with emergency device.
  • Special reducers + joints for perfect application (without cuts).
  • The machine can be extracted from the line on rails.
  • Reinforced machine frame.

Feeding speed 8-25 m/min
Working plane level 910 +/- 20 mm
Useful width 1300 mm
Conveyor belt width 1300 mm
Upper rolls width 1460 mm
Overall dimensions 1100x2700x1500mm
Chrome-plated dosing roll Ø 175 mm Kw 0,75
Rubberized spreading roll Ø 250 mm Kw 1,5
Rubberized conveyor roll Ø 240 mm Kw 1,5
Blades oscillation motor Kw 0,4
Up/down motor Kw 0,4
Installed power Kw 4,5

On request it is possible to install a spreading roll with engraved surface "LASER ROLL" able to apply bigger quantity of product (suggested for UV acrilic products, application of 15-50 gr/m2).


Roller coater for varnishes TFT/3/G2


6 indipendent speeds. Two rolls unit for base coats and top coats application (wet on wet system). With motorized blades group. Every rolls unit can be extracted for cleaning.

Spreading amount:

  • base coats from 10 to 40 gr/m2
  • top coats from 8 to 15 gr/m2

Roller coaters for special applications



Roller coater for application on glass

Roller coater for application on sheet metal (top+bottom sides of the pieces)
